| Serving Industry: | Food, Medical, Daily Chemical Industry | Type: | Conveyor Belt |
|---|---|---|---|
| Surface Material: | Silicone | Standard Length: | 100m |
| Width: | 2000mm | After Sales Service: | 6 Months |
| Oil Resistance: | Good | Material Feature: | Heat Resistant, Anti Sticking |
| Ply: | 2ply / 1ply | Package: | Customized |
| Working Temperature: | -20/+200℃ | ||
| Highlight: | High Temperature Resistant Silicone Conveyor Belt,Silicone Conveyor Belt Heat Resistant |
					||
Characteristics
Good oil & fat/grease resistance
Good resistance to solvents.
High Temperature resistance
Anti-sticking, Super-Adhesive surface, Easy release
Specification
|
			 Product Name  |

			 Silicone conveyor belt  |

|
			 Structure  |

			 2 fabric+ 1 silicone+1 PU  |

|
			 Top Feature  |

			 Silicone material  |

|
			 Middle Feature  |

			 PU material  |

|
			 Bottom Fabric Feature  |

			 laterally stiff + Polyester Fabric  |

|
			 Material  |

			 silicone+PU  |

|
			 Width  |

			 2000mm  |

|
			 Total Thickness  |

			 1.4-1.6mm  |

|
			 Length  |

			 100m/roll  |

|
			 Color  |

			 White/transparent  |

|
			 Surface  |

			 Smooth/matt/fabric embossed  |

|
			 Hardness  |

			 35 shore A  |

|
			 Tensile Force of 1% Elongation  |

			 8N/mm  |

|
			 Maximum Tensile Force  |

			 16N/mm  |

|
			 Temperature (℃)  |

			 -20/+200  |

|
			 Minimum Pulley Diameter A  |

			 40mm  |

|
			 Minimum Back Pulley Diameter B  |

			 60mm  |

|
			 Bottom Friction Coefficient (compare to steel)  |

			 0.2  |

|
			 Standard Width  |

			 2000mm  |

|
			 Bearing Way  |

			 Flat plate/ roller  |

|
			 Certificate  |

			 FDA/EC  |

Pure Silicone belt or Silicone belt with PU in the middle are available. We could produce according to your need.
Different fabric layer strutures like 1ply or 2 ply are also workable to arrange for the production.
![]()
JARULAN Silicone conveyor belts are based on food-grade quality, with a stable molecular structure that complies with FDA international safety standards.
In food baking production lines, silicone material does not release harmful substances in a 180°C high-temperature baking environment, and there is no odor residue when it comes into direct contact with bread, biscuits, etc.; in medical supplies assembly workshops, the non-toxic properties of silicone prevent equipment contamination.
High temperature resistance is the core advantage of silicone conveyor belts. Its operating temperature range can reach -60°C to 200°C. In the high-temperature steam environment of food cooking and sterilization processes, or in the hot-melt packaging of daily chemical products, the belt body does not soften or deform.
![]()
![]()
