JARULAN Factory Price 2.5mm Petrol Blue PVC Conveyor Belt 2 Ply Polyester Fabric 2000mm Width

Large Image : JARULAN Factory Price 2.5mm Petrol Blue PVC Conveyor Belt 2 Ply Polyester Fabric 2000mm Width

Product Details:

Place of Origin:	Jiangxi, China
Brand Name:	JARULAN
Certification:	ISO 9001:2015, FDA 21 CFR 175.300, EU (EC) No. 1935/2004 & (EU) No. 10/2011
Model Number:	PVC2/5SF2PB AS

Payment & Shipping Terms:

Minimum Order Quantity:	50 Square Meters
Price:	USD 8.5-15 / Square Meter
Packaging Details:	Export-grade plywood pallet with waterproof film and plastic wrap
Delivery Time:	7-15 working days
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	50000 Square Meters per Month

Contact Now Chat Now

JARULAN Factory Price 2.5mm Petrol Blue PVC Conveyor Belt 2 Ply Polyester Fabric 2000mm Width

Description

Article Code:	PVC2/5SF2PB AS	Color:	Petrol Blue
Tension Member:	Polyester Fabric	Fabric Layers:	2 EM
Total Thickness:	2.5 Mm	Weight:	2.8 Kg/m2
Standard Width:	2000 Mm	Maximum Width:	3400 Mm
Top Side:	PVC Smooth, 0.9mm, 75A Shore	Bottom Side:	Polyester Fabric
Force At 1% Elongation:	8 N/mm	Min Pulley Diameter:	55 Mm (normal), 80 Mm (back Flexing)
Temperature Range:	-10 Deg C To +80 Deg C	Applications:	Agriculture & Horticulture, Tobacco, General Handling
Highlight:	JARULAN Factory Price PVC Belt , 2.5mm Petrol Blue Conveyor Belting , 2 Ply Polyester Fabric Belt

2.5mm Petrol Blue PVC Conveyor Belt - JARULAN Factory Price

Jiangxi Jarulan Industrial Belt Co., Ltd. manufactures the PVC2/5SF2PB AS petrol blue PVC conveyor belt in-house and supplies it directly from the factory at a competitive factory price. With a 2-ply polyester fabric tension member and a smooth 0.9mm PVC top cover (75A Shore), this 2.5mm belt delivers reliable conveying for general handling, agriculture & horticulture, and tobacco processing lines.

Key Features

Factory-direct price with no middleman markup
2.5mm total thickness, 75A Shore hardness PVC top cover
2-ply polyester fabric tension member, 8 N/mm force at 1% elongation
Standard width 2000mm, maximum width 3400mm
Flat conveyor and positive drive capable
Antistatic, food-grade FDA/EU, and chemically resistant options available

Technical Specifications

Item	Specification
Article Code	PVC2/5SF2PB AS
Color	Petrol Blue
Tension Member	Polyester Fabric
Fabric Layers	2 EM
Total Thickness	2.5 mm
Weight	2.8 kg/m2
Standard / Max Width	2000 mm / 3400 mm
Top Side	PVC smooth, 0.9mm, 75A Shore
Bottom Side	Polyester Fabric
Force at 1% Elongation	8 N/mm
Min Pulley Diameter	55 mm normal / 80 mm back flexing
Temperature Range	-10 deg C to +80 deg C

Applications

Agriculture & horticulture, tobacco handling, and general material handling.

Other PVC / PU Conveyor Belt Patterns to Choose

Other PVC/ PU CONVEYOR BELT PATTERNS TO CHOOSE

PVC PU Conveyor Belt Patterns

About JARULAN

Jiangxi Jarulan Industrial Belt Co., Ltd. is a professional conveyor belt manufacturer with a factory in Red Lake Industrial Park, Jiujiang City, Jiangxi Province, China. Contact us today for a factory-price quotation.
