1mm To 8mm PVC Conveyor Belt For General Industries

I'm Online Chat Now

1mm To 8mm PVC Conveyor Belt For General Industries

1mm To 8mm PVC Conveyor Belt For General Industries
1mm To 8mm PVC Conveyor Belt For General Industries 1mm To 8mm PVC Conveyor Belt For General Industries 1mm To 8mm PVC Conveyor Belt For General Industries 1mm To 8mm PVC Conveyor Belt For General Industries 1mm To 8mm PVC Conveyor Belt For General Industries 1mm To 8mm PVC Conveyor Belt For General Industries

Large Image :  1mm To 8mm PVC Conveyor Belt For General Industries

Product Details:
Place of Origin: China
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Packaging Details: Wrapped with stretched film & Packed in pallets
Delivery Time: within 15-20 days
Payment Terms: T/T; LC,etc
Contact Now Chat Now

1mm To 8mm PVC Conveyor Belt For General Industries

Description
Working Temperature: -10/+80℃ Character: Wear-resisting
Weight: 1.8 KG/㎡ Belt Type: Conveyor Belt
Advantage: Directly Item: Conveyor Belt
Usage: Food Processing Industry Advantages: Non-toxic,Eco-friendly
Abrasion Resistance: High
Highlight:

Transport System Pallet Rubber Belt

,

Conveyor Belt Long Service Life

Product Introduction

1mm to 8mm PVC Conveyor Belt For general industries achieves stable and accurate transmission while keeping a consistent transmission ratio. Its creates low noise during work, and with good cushioning and shock absorption ability, it is able to withstand a longer service life. This belt has low pre-tension and good mechanical properties, thus ensuring good coordination with the transmission mechanism. Our 1mm to 8mm PVC Conveyor Belt For general industries is available with complete specifications and we fully support customization, so if you have any needs, please rest assured to inquire and purchase!

1mm To 8mm PVC Conveyor Belt For General Industries 0

There are different kinds of PVC conveyor belt applied in different industries according to actual working environmental needs.
1mm To 8mm PVC Conveyor Belt For General Industries 1
  1. Logistics industry (E-commerce):

    There are two kinds of materials used. One is PVC material, the other one is PVK material, such as SF, using PVK material, which is black and rough top.

  2. Food industry:

    The traditional way of cotton food conveyor belt is to use pure cotton cloth, also called pure canvas belt. But this kind of PVC cotton conveyor belt always absorbs oil and powder, which is inconvenient to clean, and is not resistant to dirt. So now, many other types of PVC conveyor belt have been developed to meet the requirements and solve problems, such as polyester cotton material pvc cotton conveyor belt, double-sided fabric pvc conveyor belt, antimicrobial conveyor belt, etc.

  3. Electronics industry:

    Anti-static function is required. There are two types, standard anti-static type and high conductivity one. Ordinary 10^8-10^9Ω can be used in ordinary environment. 10^6 to 10^8Ω can adapt to special environment. We can provide top covering anti-static, bottom anti-static, or all belt antistatic pvc conveyor belts to customers.

Please find below are some standard PVC conveyor belt from us. Please contact for more types:
Code Thickness (mm) Material Surface Bottom Color Plies 1% Extension stress (N/mm) Weight (kg/㎡) Min. roller diameter (mm) Special properties
PVC1SF1W-FDA 1.00 PVC smooth fabric white 1 6 1.2 15 FDA
PVC1/6FC2W 1.6 PVC fabric cotton Top: white Bottom: bare 2 8 1.8 20
PVC1/8FF2W 1.80 PVC fabric fabric white 2 8 1.7 40 FDA
PVC2SF2BE-FDA 2.00 PVC smooth fabric blue 2 8 2.4 50 FDA / Matt or blue color surface available
PVC3SF2BE-FDA 3.00 PVC smooth fabric /blue 2 8 3.5 60 FDA
PVC3FF2W 3.00 PVC felt fabric white 1 5 1.9 50
PVC1SF1W 1.00 PVC smooth fabric white 1 4 1.2 15
PVC1SF1BK 1.00 PVC smooth fabric black 1 4 1.2 15
PVC1MF1BK 1.00 PVC matt fabric black 1 6 1.2 20
PVC1SF1G 1.00 PVC smooth fabric green 1 4 1.2 15
PVC1SF1DG 1.00 PVC smooth fabric dark green 1 4 1.2 15
PVC1/6FF2W 1.60 PVC fabric fabric white 2 8 1.8 20 Antistatic Optional,Food Grade
PVC1/6SF2W-EF 1.60 PVC fabric fabric white 2 8 1.8 20 Food Grade
PVC2SF2W 2.00 PVC smooth fabric white 2 8 2.4 50 Antistatic Optional
PVC2DF2W 2.00 PVC diamond fabric white 2 8 2.1 50
PVC2MF2BK 2.00 PVC matt fabric black 2 8 2.4 50 Antistatic
PVC2SF2BK 2.00 PVC smooth fabric black 2 8 2.4 50
PVC2SF2DG 2.00 PVC smooth fabric dark green 2 8 2.4 50
PVC2SF2G 2.00 PVC smooth fabric green 2 8 2.4 50 Antistatic Optional
PVC2SF2BE 2.00 PVC smooth fabric blue 2 8 2.4 50
PVC2/2MF2BK-LNF 2.20 PVC matt fabric black 2 10 2.7 50 Antistatic / Low Noise Fabric
PVC2/2DF2BK-TF 2.20 PVC diamond fabric black 2 10 2.5 60 T type fabric (turning belt)
PVC2/5DF2G 2.50 PVC diamond fabric green 2 10 3.0 50
PVC2/5DF2BK 2.50 PVC diamond fabric black 2 10 3.0 50
PVC2/5MF2BK 2.50 PVC matt fabric black 2 10 3.0 50 Flame Resistance/ Low Noise/Antistatic
PVC2/6LF2BK 2.60 PVC longitudinal groove fabric black 2 10 2.7 50 Low Noise/Antistatic
PVC2/8LF2G 2.80 PVC longitudinal groove fabric green 2 8 3.2 60
PVC2/8LF2BK-FR 2.80 PVC longitudinal groove fabric black 2 8 3.2 60 Flame Resistance/ Low Noise
PVC2/8SF2PB 2.80 PVC smooth fabric petrol blue 2 8 3.3 60 Antistatic
PVC2/8BF2PB 2.80 PVC basket weave fabric petrol blue 2 8 3.1 60 Antistatic
PVC2/8SF2W 2.80 PVC smooth fabric white 2 8 3.3 60 Antistatic
PVC3MF2BK 3.00 PVC matt fabric black 2 8 3.9 50 Antistatic
PVC3SF2DG 3.00 PVC smooth fabric dark green 2 8 3.6 60 Antistatic
PVC3SF2G 3.00 PVC smooth fabric green 2 8 3.5 60 Antistatic Optional
PVC3SF2W 3.00 PVC smooth fabric white 2 8 3.5 60 Antistatic Optional
PVC3SF2SB 3.00 PVC smooth fabric sky blue 2 8 3.5 60 Antistatic
PVC3SF2BE 3.00 PVC smooth fabric blue 2 8 3.5 60
PVC3SS2-1W 3.00 PVC smooth smooth white PVC+1 fabric 8 3.1 60
PVC3SS2-1G 3.00 PVC smooth smooth green 2 PVC+1 fabric 8 3.1 60
PVC3SD2PB 3.00 PVC smooth diamond petrol blue 2 10 3.6 60
PVC3SD2G 3.00 PVC smooth diamond green 2 10 3.6 60
PVC3SD2BE 3.00 PVC smooth diamond blue 2 10 3.7 60
PVC3SD2W 3.00 PVC smooth diamond white 2 10 3.6 60
PVC3SD2W-FDA 3.00 PVC smooth diamond white 2 10 3.7 60 FDA
PVC4SF3W 4.00 PVC smooth fabric white 3 12 4.9 120 Antistatic Optional
PVC4SF3PB 4.00 PVC smooth fabric petrol blue 3 12 4.9 120 Antistatic
PVC4SF3BK 4.00 PVC smooth fabric black 3 12 4.9 120 Antistatic
PVC4SF3G 4.00 PVC smooth fabric green 3 12 4.9 120 Antistatic Optional
PVC4SD3G 4.00 PVC smooth diamond green 3 12 4.9 120
PVC4/8RF2G 4.80 PVC rough fabric green 2 12 5.4 100
PVC4/8RF2BK-FR 4.80 PVC rough fabric black 2 12 5.4 100 Flame Resistance/ Low noise
PVC4/8RF2DG 4.80 PVC rough fabric dark green 2 12 5.4 100
PVC5SF3G 5.00 PVC smooth fabric green 3 12 6.3 150 Antistatic Optional
PVC5SF3BK 5.00 PVC smooth fabric black 3 12 6.3 150 Antistatic Optional
PVC5SF3W 5.00 PVC smooth fabric white 3 12 6.3 150 Antistatic Optional
PVC5RF2DG 5.00 PVC wave rough fabric dark green 2 8 4.9 60 Antistatic Optional
PVC5RF2G 5.00 PVC wave rough rough fabric green 2 8 4.9 60 Antistatic Optional
PVC5RF2PB 5.00 PVC wave rough fabric petrol blue 2 8 4.9 60 Antistatic Optional
PVC5GF2PB 5.00 PVC golf fabric petrol blue 2 30 6.0 150
PVC5SF3PB 5.00 PVC smooth fabric petrol blue 3 45 6.1 250
PVC5DF3PB 5.00 PVC dot fabric petrol blue 3 15 5.9 120 Antistatic
PVC5RDF2G 5.00 PVC round dot fabric green 2 13 6.0 150
PVC5RDF2W 5.00 PVC round dot fabric white 2 13 6.0 150
PVC5/2RF2G 5.20 PVC rough fabric green 2 8 4.3 40
PVC5/2RF2BK 5.20 PVC rough fabric black 2 8 4.6 50 Flame Resistance/ Low Noise
PVC5/2RF2DG 5.20 PVC rough fabric dark green 2 8 4.6 50
PVC5/3RF2DG 5.30 PVC rough fabric dark green 2 8 5.3 80 Antistatic
PVC6SF4G 6.00 PVC smooth fabric green 4 16 6.5 150
PVC6SF4BK 6.00 PVC smooth fabric black 4 16 6.5 150
PVC6SF3W 6.00 PVC smooth fabric white 3 12 7.5 200
PVC6SF3DG 6.00 PVC smooth fabric dark green 3 45 7.2 200
PVC6SF4W 6.00 PVC smooth fabric white 4 16 7.1 200
PVC6DF3SB 6.00 PVC dot fabric sky blue 3 12 7.3 150
PVC7SSF3PB 7.00 PVC snake skin fabric petrol blue 3 45 8.6 250 Laterally Flexible/Stable Optional
PVC7SF3PB 7.00 PVC smooth fabric petrol blue 3 45 8.8 250
PVC7SF3SB 7.00 PVC smooth fabric sky blue 3 45 8.8 250
PVC8SQF2BK 8.00 PVC square fabric black 2 14 8.5 120
PVC8SQF2G 8.00 PVC square fabric green 2 14 8.5 120
PVC8SF3W 8.00 PVC smooth fabric white 3 45 9.8 300
PVC8/5GF3SB 8.50 PVC golf fabric sky blue 3 45 10.7 300
PVC8/5GF3PB 8.50 PVC golf fabric petrol blue 3 45 10.7 300
PVC8/5SF3G 8.50 PVC smooth fabric green 3 64 10.0 350
PVC8/5CF3BK 8.50 PVC capsule fabric black 3 15 8.2 180 Antistatic
PVC9SQF3BK 9.00 PVC square fabric black 3 14 8.5 120
PVC9SSF4PB 9.00 PVC snake skin fabric petrol blue 4 60 10.8 350 Laterally Flexible/Stable Optional
PVC9TF4DG 9.00 PVC toothed fabric dark green 4 30 5.8 200
PVC9TF4DG-0 9.00 PVC toothed fabric dark green 4 10 5.5 150
PVC9SF4PB 9.00 PVC smooth fabric petrol blue 4 64 10.5 350
PVC9/5SSF4PB 9.50 PVC snake skin fabric petrol blue 4 60 10.5 500
PVC10SF4PB 10.00 PVC smooth fabric petrol blue 4 64 10.5 500
PVC11TF3PB 11.00 PVC toothed fabric petrol blue 3 45 10.7 350
PVC11/5CF4SB 11.50 PVC capsule fabric sky blue 4 60 10.8 350 Shore Hardness 65A/75A Optional
PVCR12SF4R 12.00 PVC rubber fabric red 4 20 15.5 200
PVC13OTF4PB 13.00 PVC one-way toothed fabric petrol blue 4 60 10.8 350 Laterally Flexible/Stable Optional,Shore Hardness 65A/75A Optional
PVC13TTF4PB 13.00 PVC two-way toothed fabric petrol blue 4 60 10.8 350 Laterally Flexible/Stable Optional,Shore Hardness 65A/75A Optional
PVC13TTF4SB 13.00 PVC two-way toothed fabric sky blue 4 60 10.8 350 Laterally flexible/stable Optional,Shore hardness 65A/75A Optional
PVC13OTF4SB 13.00 PVC one-way toothed fabric sky blue 4 60 10.8 350 Laterally Flexible/Stable Optional,Shore Hardness 65A/75A Optional

*Available for other thickness and sizes.

**Maximum production width 3500mm is available.
